Nice Apollo Mercury 310 UL 325 Residential Smart Control Board - MX4920
Details
Nice Apollo Mercury 310 UL 325 Residential Smart Control Board - MX4920
The Nice Apollo Mercury 310 Smart Control Board is a UL 325 safety compliant controller designed for use with residential linear swing gate actuators. It features an easy-to-understand, user-friendly controller interface, meaning no need to hire a professional installer to achieve the full functionality and safety needed for controller setup. By integrating redundant internal safety functions and automating many of the typical setup steps, the Mercury 310 ensures full UL 325 safety compliance while also achieving powerful features and accurate configurations.
The Mercury 310 Controller can be used in both AC and Solar powered applications and comes with an integrated battery charge controller with MPPT technology that optimizes battery charging from a wide variety of solar panels. In standby mode, it maximizes battery life and efficiency with its minuscule standby current while also featuring a prominent Battery Health LED warning that alerts the user about any potential power issues. Additionally, it has two built-in accessory ports that are designed for foolproof support of both BlueBUS and 10K Monitored External Entrapment Sensors.
Features:
- Single or Dual Gate Opener Applications
- Safety Rating: UL 325 7th Edition Compliant
- Designed For Use With Residential Linear Swing Gate Actuators
- Built-In UL 325 Type C Force Entrapment Protection**
- Solar Battery Charge Controller With MPPT Designed For Wide Variety of Solar Applications
- User-Friendly Design Makes Set-Up and Controller Parameters Easy To Understand - No Programming Needed
- Quick and Easy One-Step Firmware Update Process
- Very Low Standby Current Maximized Battery Life in Solar Installations
- LED Battery Health Warning Alerts Users of Potential Battery Issues
- Fully-Integrated Compatibility With BlueBUS and OXI Accessories
- User Controls: Function Selection Dial, Open, Close, Stop/Clear Buttons, Value Adjustment Increase/Decrease Buttons, Remote Programming Buttons
**We are committed to safe, smart gate automation and recommend the use of additional external safety devices when possible for maximum protection.
Learn More About Our UL 325 Safety Compliance Standards
Technical Specifications:
- Model: Mercury 310
- Solar Compatible: Yes, 12V With MPPT
- Input Voltage: 18 - 24 VDC
- Maximum Current: 30A
- Accessory Power: 12V 500mA Always On (2 Locations), 12V 500mA Standby Off (2 Locations)
- Communication: BlueBUS, USB Port, OXI, Fire Input, 433 MHz Remote
- Dimensions: 7.3" (W) x 7.2" (H) x 1.2" (D)
- ETL Listed (UL 325): Usage Class I, II
- External Entrapment Sensor Options: BlueBUS and 10K Monitored Sensors
- Relays: None
- Operating Temperature: -4° F to 122° F (-20° C to 50° C)
**Please Note: The Mercury 310 Controller Requires An Encoder To Operate, Therefore It Is Not Compatible With Nice Apollo 416 Actuator Arms And Can Only Be Used With The 816-BLK, 816X-BLK, and Titan Actuators.
Products Powered By Mercury 310:
Check Out More Mercury 310 Videos Here
| SKU | MX4920 |
|---|---|
| Operator Compatibility | Apollo 1500, Apollo 1550-1K, Apollo 1550ETL, Apollo 1551, Apollo 1600, Apollo 1650-1K, Apollo 1650ETL, Apollo 1651, Apollo Titan12L, Apollo Titan12L1 |
| Manufacturer | Nice Apollo Gate Operators |
| Condition | New |
| BlueBUS Compatible | BlueBUS Compatible |
| Input Voltage | 12 DC |
